Product specifications:
Electronic stop sign can belong to LCD or LED text display video bus lines waiting screen display, advertising, bamboo
small car station reported information, WIFI Internet access, video surveillance within the site, and many other features
of the integrated product.

Product Features:
1. Eye-catching, stylish, open appearance, with contemporary urban atmosphere in major cities;
2. Flexible display modes,strong extensibility,various information display formats for your choice and free combination
   such as 32 inch LCD TV,LED dot-matrix screen,dedicated line waiting screen and so on.
3. Backlight turns on automatically at night, the passengers can clearly check the station name,station program,
  advertising and other promotional instructions.
4. Can real-time communicate with the system background,and real-time exchange the stop condition,vehicle
  condition information and so on,real-time control or update the stop system.
5. Can real-time monitor the safety condition and running condition of the station board,if the stop sign for illegal entry
   or abnormal operation, it will warning and records timely.
6. Can set working time of the station board,automatically open and close the electronic station board working circuit.
7. P6 single-line 8-word propaganda LED screen,beautiful,simple,practical,can real-time release public information,
   weather, advertisements, system notices or waiting information and so on.
8. 32-inch LCD TV screen:it can real-time display the vehicle location,surrounding landmarks,multimedia audio and
   video,advertising,broadcast,public information,weather, system notifications,waiting message (the nearest two buses
   of each waiting line away from the station you are waiting bus line No.,distance,the expected arrival time)in map
  format and so on.
9. Line waiting screen:it can intuitively real-time display the moving position of the nearest three shifts of waiting line,
  and can instruct waiting instructions and traffice instructions according to the station sequence tables.Vehicle-shape
  Color:Green-loose, yellow-moderate,red-crowded,beneath the vehicle-shape symbol is the relative LED
  Color: Green-running smoothly, yellow-Postponed,Red-traffic jams,support in text display the departure time ,stop
  running,bypass,line changes of current lines and other information.
10. Can real-time voice broadcast the waiting information.
11. Can real-time video monitoring ambient conditions before and after the stop sign, and can be video recording
  and remote view.
12. Can real-time temperature monitoring the internal core temperature of stop sign,if high temperature condition
  for early warning and cooling automatically.
13. Provides free Wi-Fi access,convenient,fast,save flow,achieve waiting information query functions.
14. System background can remotely monitor, control video playback,preview video,release notice and promotional
  message, and other remote configuration and upgrades.

Model

TM5011 series

Power supply

Mains supply 220V power supply

Installation

Embedded fasteners

Stop sign working time

Can be set

 Protection Classification

Dustproof, waterproof, prevent erosion and so on

Environmental Requirement

Temperature:-20℃~+60℃,Relative humidity≤90% (when 25℃±5℃)

LED dot matrix screen display

P6 single line 8 characters LED dot matrix screen,
the background can be issued by a public/Advertising
 Information

LCD TV display

32 inch LCD TV(optional):
1.According to the environmental light intensity, can
 automatically light induction and adjust backlight brightness
2.Waiting information can map display and text display,
 friendly interface.
3.Can locally and remotely configure the line number,station distance,distance,passenger traffic/comfort,
expected arrival time and other bus waiting information display
4.Can display 10 lines information,each route will display the nearest two buses information.
5. Advertisement/promotional information can be displayed in videoand text format,friendly interface,
will not interrupt the normal display of routes information.
6. Advertisements and promotional information can be configured and updated remotely.
7.The background can automatically download the video files through pages and can loop playback
and normal playback.
8.Can set the beginning and ending time of multi-media
9.Different electric station board can set different media to play and control.
Line waiting screen display
Routes waiting screen can be optional(optional)
1.Each route will configure one route waiting screen(if above 4,will need customize)
2.Can show the intuitive routes dynamic information for the passengers,real-time display the image show of the nearest three buses away from this station,will indicate the relative waiting information through corresponding to station order tables
3.When the buses are driving,”public bus”will blink,when they stop or arrive at station,”public bus”stop blink.
4.When the current station of route have no buses,will display next bus departure time.
5.Can signify the passenger number of the upcoming buses,The color of the graphics of ”public bus”will show
the waiting passenger number of upcoming buses,green show loose,yellow show moderate,red show crowd.
6.Can show the road traffic condition of relative roads corresponding to station order table,by different color
to indicate the road congestion,at least can show three status:green-unobstructed,yellow amble,red-traffic jam
7. With self-inspection function,can automatically detect
 if there are bad points on route screen,if the communication is normal and so on.
8. Support text information display function,can display the necessary text information on screen,such as lines.
9.When the operation is end,or the last bus has arrived this station,the screen will display “operation is end”prompt.
Voice broadcast
Voice broadcastoptional):
1.Waiting and arriving at station information can be real-time reported.
2.Voice is clear,no stop,delayed abnormal phenomena,the volume can be adjusted.
3.Sound quality is good,no obvious noise,the volume is moderate
Video monitoring
video monitoringoptional):
1.Maximum support 2 channel pinhole camerato collect video(front and rear has different channel )
2.Support local video playback
3.Support remotely check/preview/download video files(but will consume large flow )
Wi-Fi hotspot
Wi-Fi hotspot functionoptional):
1.Passengers can access the network hotspot sent by electric station board wifi equipments through mobilephone,
can download Mobile Phone Client(APP),and inquire the waiting information,transfer query, routes query,station query and other travel information,
accept relevant commercial information such as advertisements,
peripheral business information,group purchase,special Offers(LBS) and so on.
2. The striking position of housing can layout advertising
stickers with and two-dimensional code scanning and prompt message function
(to be customized),to guide passengers to use WIFI connection,
 APP download, receive special offers by scanning the QR code.
Timing lighting
Automatically open the back lighting at night,convenient for
passengers to clearly check the station,station order,advertisement
and other propaganda instructions
